Tripp Lite SRWF5U 5U Low-Profile Wall Mount Enclosure (black). Fixed wall bracket.

SMARTRACK™ Series

SRWF5U

SmartRack 5U Low-Profile Wall Mount Rack Enclosure Cabinet

Need to wall mount equipment in environments with limited floor space? The SRWF5U Low-Profile Wall Mount Rack enclosure securely mounts standard 19" rackmount equipment vertically up to 5U in depth and up to 20 inches in length in a low-profile wall mount enclosure. Great for back office and network closet applications where floor space is limited.Designed for IT and education environments where equipment needs to be secure and out of the way5U with adjustable/reversible rackmount rails2U slide-out mounting brackets for patch panelsLocking, reversible front door Fully assembled for quick installationMeets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) Compliance

Overview

The SRWF5U 5U+2 Low-Profile Wall Mount Rack Enclosure Cabinet is designed to integrate wall-mounting, easy equipment access, and cable management in IT network applications with limited floor space. Ventilated front door and bottom panels allow generous airflow to keep equipment operating safely. Adjustable horizontal rack rails securely mount 5U of 19" rackmount equipment with M6 or they can be reversed for securing with 12-24 threaded mounting holes. The patch panel mounting brackets provide space for up to 2U of patch panels with integral slide-out feature for easy cable access. Supports up to 150 lbs of equipment.

Key Features

 5U low-profile wall-mounted enclosureAdjustable horizontal mounting depths from 17" to 20" inchesSlide-out mounting brackets provides 2U of space for patch panel(s)Ventilated front door and bottom panels for increased airflowLocking, reversible front doorMultiple keyhole mounting slots for wall mountingFully assembled for quick installationMeets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) compliance

Typical Applications

IT network environments, back office, and network closets with limited floor space and classrooms where equipment needs to be secure and out of the way of students.
Package Includes

 SRWF5U Low-profile wall-mount enclosure(12) M6 screws(12) M6 cup washers(12) 12-24 screws(2) KeysOwner's Manual
Specifications
PHYSICALInstalled whole system maximum rack depth (inches)20Installed whole system maximum rack depth (cm)50.80Installed whole system minimum rack depth (inches)17Installed whole system minimum rack depth (cm)43.18Rack Height5UShipping Dimensions (HWD/in)31.5" x 27.6" x 12"Shipping Dimensions (HWD/cm)80.01 x 70.10 x 30.48Shipping weight (lbs)49Shipping weight (kg)22.1Unit Dimensions (in.)EXTERNAL DIMENSIONS: 28.8" x 25.6" x 9.7" (HWD)Unit weight (lbs)29Unit weight (kg)13Unit Dimensions (cm)73.15 x 65.02 x 24.64ColorBlackStyleWall MountedWeight Capacity - Stationary (lbs)150Weight Capacity - Stationary (kg)68.0CERTIFICATIONSCertificationsEIA-310-ENOM (Mexico)Tested to NOM (Mexico)ApprovalsRoHSWARRANTYProduct Warranty Period (Worldwide)5-year limited warranty
